The RME Digiface USB is a professional-grade audio interface that effortlessly transfers large amounts of digital audio data in ADAT and S/PDIF format to your computer. With four optical I/Os and real-time mixer software, it offers a total of 32 inputs and 34 outputs for versatile recording and monitoring. Lightweight and compact, it's perfect for on-the-go use.

The Digiface USB is a compact audio interface that provides 32 channels of I/O with high-resolution audio support. It features ADAT and SPDIF connectivity, making it versatile for various digital audio setups. With its USB connection and TotalMix FX software, it offers flexible routing and mixing options for professional audio applications​


Features

• Interface: USB 2.0, bus-powered, no external power supply required
• Sample rates: 28 kHz to 200 kHz
• 66 channels: 32 in / 34 out
• 4 x ADAT / S/PDIF optical input ports
• 4 x ADAT / S/PDIF optical output ports
• Standard speed: 32 channels, 24-bit/up to 48 kHz, record/playback via ADAT optical
• Double speed: 16 channels, 24-bit/96 kHz, record/playback via ADAT optical (S/MUX)
• Quad speed: 8 channels, 24-bit/192 kHz, record/playback via ADAT optical (S/MUX4)
• Each single optical port can use either ADAT (up to 8 channels) or S/PDIF (stereo)
• ADAT and S/PDIF I/Os can be used simultaneously
• One analog line/headphone stereo output, provides separate output for independent submix
• All settings can be changed in real-time
• TotalMix allows for practically unlimited mixing and routing operations, with all inputs and playback channels simultaneously, to any hardware outputs, with 46-bit internal resolution
• TotalMix for latency-free submixes and ASIO Direct Monitoring
• Compact, portable, and lightweight audio interface
• Slave and master clock modes – Internal, ADAT input, S/PDIF input
• Buffer sizes/latencies 32 to 8192 samples, selectable
• Automatic and intelligent master/slave clock control
• SteadyClock: Jitter-immune, super-stable digital clock
• SyncAlign guarantees sample-aligned and never-swapping channels
• SyncCheck tests and reports the synchronization status of input signals
• DIGICheck DSP: Level meter in hardware with peak and RMS calculation
• High-resolution Bitclock PLL (audio synchronization) in ADAT mode, even in vari-speed operation
• Near-zero effective clock jitter influence on A/D and D/A conversion
• PLL ensures zero dropout, even at more than 100 ns jitter
• Low-Jitter Design: < 1 ns in PLL mode, all inputs
• Driver CD contains drivers for Windows Vista / 7 / 8 / 10 and Mac OS X (x86 Intel)
