Introducing the Orion 32+ | Gen 4, the latest in Antelope Audio's renowned line of interfaces that has set industry standards for over a decade. This new iteration builds on its predecessors' strengths, meeting today's evolving demands with advanced technology.

Combining Thunderbolt 3 and USB 2 connectivity with ADAT, MADI, and S/PDIF compatibility, the Orion 32+ | Gen 4 offers 32 inputs and 34 outputs for flexible recording and mixing solutions. It features pristine AD/DA conversion and Antelope Audio's 64-bit Acoustically Focused Clocking (AFC) technology, ensuring high fidelity audio up to 24-bit/192kHz.

Housed in a robust 1U rack-mountable design, this interface is suitable for both professional studios and live environments. With powerful DSP processing via Synergy Core technology, users can efficiently run a variety of effects and plugins with minimal latency directly on the interface.

Discover the pinnacle of audio interface technology with the Antelope Audio Orion 32+ | Gen 4, delivering unmatched versatility, quality, and performance in a compact rack unit.

Antelope Audio ORION32+/GEN4 Features:

• 32 Channels DC-Coupled AD/DA Conversion
• 128 Channels I/O via Thunderbolt 3, MADI
• Up to 24-Bit / 192 kHz Resolution
• Supports USB, MADI, ADAT, and S/PDIF
• Expanded Dynamic Range, Lower THD+N
• 64-Bit Acoustically Focused Clocking
• 2 Wordclock Outs,10 MHz Atomic Clock In
• Preset System for Easy Recall
• Comprehensive Software Control

Antelope Audio ORION32+/GEN4 Specifications:

• Form Factor: Rackmount
• Display: OLED
• Channels of I/O Thunderbolt: 128 Inputs / 128 Outputs
• MADI: 128 Inputs / 128 Outputs
• USB: 32 Inputs / 32 Outputs
• Analog: 32 Inputs / 32 Outputs
• ADAT: 8 Inputs / 8 Outputs
• S/PDIF: 2 Inputs / 2 Outputs
• Built-In DSP: Yes
• Maximum Sampling Rate: 192 kHz / 24-Bit
• Number of Microphone Preamps: None
• Built-In Microphone: None
• Expansion Slots: None
• Signal Processing:
• Pad: None
• Connectivity:
  • Analog Audio I/O:
    • (4) DB-25 25-Pin Balanced 8-Channel Input
    • (4) DB-25 25-Pin Balanced 8-Channel Output
    • (2) 1/4" TRS Balanced Monitor Output
  • Phantom Power: None
  • Digital Audio I/O:
    • (1) TOSLINK Optical ADAT Input
    • (1) TOSLINK Optical ADAT Output
    • (1) RCA Coaxial S/PDIF Input
    • (1) RCA Coaxial S/PDIF Output
    • (2) SC-Plug Optical MADI Input
    • (2) SC-Plug Optical MADI Output
  • Host Connection / USB:
    • 1 Thunderbolt/Mini DisplayPort
    • 1 USB-B
  • Host Connection Protocol:
    • Thunderbolt 3
    • USB 2.0
  • USB (Non-Host): None
  • Sync I/O:
    • 1 BNC Atomic Clock Input
    • 1 BNC Word Clock Input
    • 2 BNC Word Clock Output
  • Network I/O: None
  • MIDI I/O: None
  • Wireless: None
  • Wireless Connectivity: None
• Performance:
  • Maximum Input Level: Line Inputs: +24 dBu
  • Maximum Output Level: Line Outputs: +24 dBu
  • Dynamic Range: A/D Converters: 122 dB
  • D/A Converters: 130 dB
  • Monitor Outputs: 130 dB
  • THD+N: A/D Converters: -116 dB
  • D/A Converters: -115 dB
  • Monitor Outputs: -115 dB
• Digital Audio:
  • Sample Rates: Up to 192 kHz
  • Bit Depths: Up to 24-Bit
  • Sync Sources: ADAT, Atomic Clock, Internal, S/PDIF, Word Clock
  • Clocking: Word Clock
  • Input Termination: 75 Ohms
• Audio Storage & Playback:
  • Memory Card Slot: None
  • Compatibility:
    • OS Compatibility:
    • macOS 10.11 or Later
    • Windows 10
    • *As of November, 2021: Check with manufacturer for the most up-to-date compatibility
  • Included Software: None
  • Processor Requirement:
    • Mac: Intel Core 2 Duo
    • PC: 2 GHz Intel, 2 GHz AMD
  • RAM Requirements: 4 GB, 8 GB Recommended
  • Storage Requirements: 512 MB
  • Mobile App Compatible: No
  • *As of May, 2023: Check with manufacturer for the most up-to-date compatibility
  • Mobile Device Compatibility: None
• Required Hardware:
  • Available Thunderbolt Port or USB-A Port
  • USB Cable (Included)
  • Thunderbolt Cable (Not Included)
  • Internet Connection: Required for Registration
• Power:
  • Power Requirements: AC Input
• Physical:
  • Rackmount Size: 1 RU (with Included Hardware)
  • Operating Temperature: 32 to 122°F / 0 to 50°C
  • Dimensions: 19 x 11 x 1.73" / 48.3 x 27.9 x 4.39 cm
  • Weight: 7.4 lb / 3.4 kg
