HK LINEAR-7-115-FA 200 Watt 15" Active Speaker
The HK LINEAR-7-115-FA 200 Watt 15" Active Speaker is built for real-world live sound where you need strong low-end authority, high output, and a setup that stays predictable from venue to venue. If you’re running mains for a band, powering a DJ rig, or building a scalable event system, this is the kind of speaker that gives you headroom you can actually use.
With a network-compatible DSP platform, a biamped Class D design, and a dedicated Bass Boost preset tuned for the cabinet, the HK LINEAR-7-115-FA 200 Watt 15" Active Speaker is easy to tailor for different rooms without overcomplicating your workflow. The rotatable 60° x 40° CD horn also helps you keep coverage controlled—especially when you’re working in tighter spaces or aiming for cleaner throw.
More Low-Frequency Weight When You Need It
The larger cabinet volume is designed to deliver more sound pressure in the low-frequency range, which matters when you’re trying to keep kick, bass, and full mixes feeling solid without pushing your system into strain. When the room calls for it, the Bass Boost preset lets you lift the low end in a controlled, repeatable way.
Controlled Coverage with a Rotatable CD Horn
The 60° x 40° CD horn is rotatable, which makes a difference when you’re placing speakers horizontally or working around stage constraints. It’s an underrated advantage for cleaner coverage, more consistent vocal projection, and fewer “hot spots” in challenging rooms.
Network DSP Control for Scalable Systems
If you’re building a multi-speaker rig, network control helps you keep everything aligned and consistent. The speaker supports DSP CONTROL (Windows, Mac OS), with tools like a fully parametric 10-band EQ, filters, delay, polarity, limiting, and mute—so your tuning is precise without turning setup into a science project.
Highlights
- Biamped Class D design with 2000 W peak power output
- High output performance up to 134 dB peak SPL (half space)
- Bass Boost preset for tailored low-frequency enhancement
- Rotatable 60° x 40° CD horn for controlled coverage
- Network-compatible with DSP CONTROL remote software
In real-world use, the HK LINEAR-7-115-FA 200 Watt 15" Active Speaker is a strong fit for FOH mains, side-fill, or a punchy top box in a system that can scale up over time. It’s also a practical choice for event production where repeatability matters—save your tuning approach, keep your coverage consistent, and focus on the show instead of constantly reinventing your speaker settings.
If you’re building out a complete rig, explore our PA speakers for matching options, or add serious low-end support from our subwoofers. For more system expansion ideas.
HK LINEAR-7-115-FA Active Speaker Technical Specifications
| Specification |
Details |
| Max. SPL @ 10% THD |
129 dB half space (70 Hz – 12 kHz averaged) |
| Max. SPL Peak @ 10% THD |
134 dB half space |
| Frequency Response (±3 dB) |
57 Hz – 19 kHz |
| Frequency Response (-10 dB) |
54 Hz – 20 kHz |
| Power Amp Output (Peak Power) |
2000 W |
| Amp Type |
Class D - biamped |
| Low-/Mid Speaker |
1 x 15", 3" voice coil |
| HF Driver |
1", 1.7" voice coil |
| Horn Directivity |
60° x 40° CD horn, rotatable |
| Active Crossover Frequency |
1.5 kHz FIR X-over with 60 dB/oct. |
| Maximum Input Level |
+20 dBu |
| Analog Inputs |
1 x XLR combo balanced |
| Analog Thru |
1 x XLR balanced |
| DSP Out |
1 x XLR |
| Network Port |
Ethercon RJ45, 1 x In, 1 x Thru |
| Filter Presets |
Flat, Boost, Low Cut, Remote |
| Remote Software |
DSP CONTROL (Windows, Mac OS) |
| DSP Functions |
Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute |
| Sample Rate |
96 kHz |
| System Latency |
Less than 2.6 ms |
| Mains Connector |
1 x Powercon NAC3 In, 100–240 V |
| Power Consumption |
1 A / 100–240 V nominal according to EN 62368-1 |
| Clustering Angle |
60° |
| Pole Mount |
DuoTilt 3°/7° |
| Rigging Points |
4 x M8 (AP-8) |
| Carrying Handles |
2 x MultiGrip |
| Housing |
Hybrid (birch multiplex/MDF) |
| Finish |
Black acrylic enamel |
| Front Grille |
2 mm metal grille backed with black acoustic foam |
| Dimensions (W x H x D) |
45 x 71 x 45 cm (17-23/32 x 27-61/64 x 17-23/32") |
| Weight |
32 kg / 70.5 lbs |
What’s in the Box
| Included Items |
| HK LINEAR-7-115-FA 200 Watt 15" Active Speaker |
| Power cable (Powercon connection) |
| User manual |
