The Fireface UCX II is a highly integrated pro-audio solution in an ultracompact format for studio and live recordings. It continues RME's long tradition of designing advanced compact interfaces, packing into a half-rack size unit what usually would be spread outover two or three 19" panels.



With up to 20 channels for recording and playback, SteadyClock FS, high-performance microphone inputs, parametric EQ, dynamics processing, echo, reverb, DURec (Direct USB Recording), MIDI I/O, a powerful headphone output, and full standalone operation, the Fireface UCX II excels with RME's highest feature-to-space ratio ever.

• The Fireface UCX II comes with the TotalMix FX DSP mixer offering comprehensive routing and monitoring options, as well as the DIGICheck Analyzer allowing to measure and analyze the digital data feed in both directions with maximum precision.
• The integration of Room EQ adds room calibration to the RME eco-system, making your Fireface perfect for Immersive audio setups including Dolby ATMOS. Room EQ consists of nine bands of fully parametric EQ, individual output delay, and volume calibration. Users can freely assign up to twenty 20 Room EQs at once to any output(s) they wish including stereo, headphone, and digital outputs for maximum flexibility. Settings can be input manually or imported using tools like Sonarworks or Room EQ Wizard.
• Also added is a feature called Binaural Crossed. This functionality provides speaker emulation in headphones-perfect for mixing stereo or ATMOS in headphones. The Crossfeed function emulates speaker behavior in terms of channel separation, so the extremely wide ambience experienced in headphones can be set in 5 stages.

• Full standalone operation, no computer required
• DURec-integrated digital recorder allows you to record directly to USB memory devices
• All channels (20 inputs and 20 outputs) can be individually chosen for recording and playback
• CV/gate low-latency voltage control for automating synthesizers, mixing consoles, and effects
• SteadyClock FS reference-class digital clocking
• USB out for ARC USB remote control (available separately)
• Compatible with TotalMix FX for iPad
• DIGICheck turns the interface into a highly versatile front-end for audio measurements and software development
• Class-compliant mode for Linux environments and compatibility with iPads and iPhones (separately available connection kits may be needed)
• Crisp high-resolution color display shows metering for all input and output channels

• Two XLR-1/4" combo mic/line preamps with phantom power and up to 75 dB of gain, plenty even for low-output dynamic mics such as the Shure SM7B
• Two 1/4" TRS inputs for balanced line-level sources or unbalanced Hi-Z instruments
• Input sensitivity for line/Hi-Z inputs switchable to 19 or 13 dBu
• Four rear-panel balanced 1/4" TRS line-level inputs with up to 12 dB of gain, perfect for patching in synths or outboard gear
• All analog inputs are digitally controlled

• Six balanced 1/4" TRS line outputs with high dynamic range (115 dBA) and three selectable output levels (+19, +13, or +4 dBu)
• High-power 1/4" stereo headphone output

• 8-channel ADAT I/O via TOSLINK optical ports
• 2-channel AES3 I/O via breakout cable
• 2-channel S/PDIF I/O via breakout cable
• USB-B host connection for Mac/Windows/Linux supports USB 2.0 and 3.0 standards

• DIN 5-pin MIDI I/O for connecting keyboard controllers, arranger workstations, and synthesizers
• BNC wordclock jack can be assigned as an input or output
• Barrel input for included power adapter
