More I/O. No Compromise. Ready for Your Hybrid Workflow.

If you’re building a hybrid setup where outboard gear, analog summing, or immersive monitoring is key, the Symphony Studio 8x8 gives you the I/O count you need—without stepping into oversized, overbuilt systems. You get 8 analog inputs and 8 analog outputs with Apogee’s renowned AD/DA clarity, ultra-low latency USB-C connectivity, and onboard DSP processing for both input channels and speaker tuning. All packed into a 1U interface that’s easy to integrate, easy to control, and ready for real-world studio demands.

Whether you're tracking a full rhythm section, routing audio to external processors, or mixing in 7.1.4 Dolby Atmos, the 8x8 delivers the detail, routing flexibility, and reliability your setup depends on.

Key Features

• 8x8 analog I/O for hybrid routing, analog gear, and immersive monitoring

• Apogee-class AD/DA conversion up to 192kHz / 24-bit

• USB-C interface with ultra-low latency for real-time tracking and playback

• Built-in DSP for input processing and room calibration

• Dual headphone outs with independent routing and zero-ohm design

• Symphony Control software for flexible, streamlined control

• Designed for Dolby Atmos support up to 7.1.4

Built-In DSP

• Input DSP: Apogee Channel Strip with EQ, compression, and analog-style drive

• Output DSP: Room EQ and monitor tuning tools for precise speaker response

Audio Specifications

• Mic Pre Gain: Up to 75dB

• A/D Dynamic Range: 124 dB (A-weighted)

• D/A Dynamic Range: 128 dB (A-weighted)

• Sample Rate: Up to 192kHz

• Bit Depth: 24-bit

• Connection: USB-C, class compliant

I/O Configuration

• 8 x combo XLR/TRS analog inputs (mic/line/instrument capable)

• 8 x balanced line outputs via DB25 connector

• 2 x 1/4” TRS headphone outputs with independent routing

Build & Dimensions

• Chassis: 1U rackmount

• Boxed Dimensions: 22.875" x 17.75" x 9.25" (58.1 x 45.1 x 23.5 cm)

• Weight: ~19.1 lbs (8.7 kg)

What’s in the Box

• Apogee Symphony Studio 8x8 Interface

• USB-C cable

• Power cable

• Quick start guide

• Warranty and registration materials

Compatibility

• macOS Ventura and later

• Windows 10 and later

• Works with all major DAWs: Logic Pro, Pro Tools, Cubase, Ableton Live, Studio One

• Core Audio and ASIO driver support

Who It's For

If you're running a rack of outboard gear, tracking multiple sources at once, or diving into immersive formats like Atmos, the Symphony Studio 8x8 was made to keep up—with uncompromising sound quality and workflow-first design.
