RME ADI-6432 - 64-Channel, 24-Bit/192kHz MADI / AES Format Converter

RME ADI-6432 - 64-Channel, 24-Bit/192kHz MADI / AES Format Converter

The RME ADI-6432 is a professional sixty-four-channel format converter, providing high-quality conversion between MADI and AES formats. With SteadyClock technology for low jitter operation and intelligent clock control, this unit is ideal for use as...

Type : Converters

Availability : In stock Out of stock

$4,599.00
$4,599.00
On Sale! Sold out
Shipping calculated at checkout.

Tags : Converters

Collections : Converters

Shipping & Returns

  • We deliver all US domestic orders within 6-10 business days!
  • Cancelations are completely free of charge
  • Returned Items must be unused and in original packaging
  • Most items can be returned within 30 days of delivery unless otherwise noted

No Sales Tax On Your Order

  • No sales Tax On Your Order Except GA*

Why Shop With Us

  • Authorized Retailer for KMC music, Antelope audio and RME
  • ZERO Sales Tax (for Georgia Residents)
  • Speak with an Expert Today at 470-823-8373
View full details

The RME ADI-6432 is a professional sixty-four-channel format converter, providing high-quality conversion between MADI and AES formats. With SteadyClock technology for low jitter operation and intelligent clock control, this unit is ideal for use as a digital multi-core or AES/EBU front end for the Hammerfall DSP MADI PCI card. Transfer up to sixty-four channels of 24-bit audio at various sampling frequencies with ease.

The ADI 6432 R is a 64-channel MADI-to-AES/EBU converter with redundancy features for increased reliability. It offers high-quality AD/DA conversion and SteadyClock FS technology, ensuring ultra-low jitter and high audio fidelity for professional audio applications

Features

  • Sixty-four channel MADI/AES format converter
  • Support for up to 192kHz sample rates with MADI and AES
  • Supplies word clock in Single, Double and Quad Speed, distributes Double Wire 96kHz signals into the MADI data stream and to the AES ports and supports the double MADI sample rate (96k frame)
  • SyncAlign and SyncCheck technologies ensure perfect synchronization and clear detection of errors
  • Extensive status displays give information about Lock and Sync states, audio content and the physical quality of the incoming signal
  • A fully automatic input selection between optical and coaxial input offers a useful redundancy mode for critical applications
  • Multiple units can be stacked and operated sample-aligned, using word clock.
  • MADI Merge, using two units, allows two MADI streams to be merged from two sources, and sent on via a single MADI cable. Useful in situation where the two sources are not utilizing their full sixty-four channel counts
  • The unit can be also used as a MADI to MADI converter. For instance, an AMS Neve Logic DFC only accepts the fifty-six channel input format. The ADI-6432 can read either format at its input or output
  • All settings are stored when the unit is switched off
  • Sixteen MIDI channels can be transferred across MADI even with sixty-four audio channels
  • The device can be fully remote controlled and configured via MIDI and all status displays can be queried through MIDI
  • Each unit in a multiple-unit setup can be given a separate ID, allowing separate remote control of the devices utilizing only a single MIDI channel
  • Compatible to MADI interfaces of companies like Sony, Merging, Lawo, Euphonix, Stagetec, Jünger, Audio Service, AMS and others
